IKA® VAN-1 Vane Spindle Set for Rotavisc, 25000407

The IKA VAN-1 is a complete vane spindle set for ROTAVISC viscometers, designed to measure the viscosity of gels, pastes and settling suspensions without disturbing their structure. The set includes the five vane measuring spindles VAN-SP-1 through VAN-SP-5, covering a wide viscosity range. Spindles are made of stainless steel 1.4404.

Country of Origin: Germany

Warranty: Comes with 2+1 Year Manufacturer's Warranty. See details here

Specifications:

Spindle geometry	Vane
Connection	Thread M2.5 LH
Quick plug connector	yes
Hook connector	yes
Sample volume	500 ml
Sample container	600 mL beaker low
Working temperature max.	300 °C
Viscosity Accuracy (FSR)	2 %
Viscosity Repeatability (FSR)	0.2 %
Min. FSR match ROTAVISC lo-vi	24.6 mPa.s
Max. FSR match ROTAVISC lo-vi	5100000 mPa.s
Min. FSR match ROTAVISC me-vi	262 mPa.s
Max. FSR match ROTAVISC me-vi	54300000 mPa.s
Min. FSR match ROTAVISC hi-vi I	524 mPa.s
Max. FSR match ROTAVISC hi-vi I	108600000 mPa.s
Min. FSR match ROTAVISC hi-vi II	2100 mPa.s
Max. FSR match ROTAVISC hi-vi II	434000000 mPa.s
Material in contact with medium	stainless steel 1.4404
Dimensions (W x H x D)	160 x 82 x 270 mm
Weight	0.432 kg

Product Data Sheet
